Cheap MH1525 Automatic Finger Joint Assembler Machinery for wood

FOB Reference Price:Get Latest Price
$1,000.00 - $2,000.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
MH1525
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 10 >10
Est. Time(days) 20 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Spindle Speed:
2840r/min
Air Pressure:
0.8Mpa
Max. Working Width:
350mm
Max Working Height:
2500mm
Place of Origin:
Shandong, China
Brand Name:
KINGISO
Voltage:
380V/50Hz
Dimension(L*W*H):
3600*1050*1500mm
Certification:
CE ISO
Warranty:
12 Months, 12 months
Max.working length:
2500mm
Max.thrust for oil pressure:
4000kg
Worktable size:
2500x350mm
Max.working thickness:
70mm
Oil pump power:
2.2kw
Cut off saw power:
1.5kw
Main spindle speed:
2840r/min
Max.blade diameter:
305mm
Net weight:
500kg
After-sales Service Provided:
Engineers available to service machinery overseas
Power(W):
saw 1.5kw
Weight:
500kg
Supply Ability
Supply Ability:
100 Set/Sets per Month Finger Joint Assembler Machinery
Packaging & Delivery
Packaging Details
By stretch film with wooden case or customized.
Port
Qingdao Shanghai Guangzhou or as your request
Lead Time :
Quantity(Sets) 1 - 10 >10
Est. Time(days) 20 To be negotiated

Cheap MH1525 Automatic Finger Joint Assembler Machinery for wood

Product Description



Application:

The finger joint assembler machine is a special butt joint machine. With special glue, the old wood and short wood can be reused.The wood after joining can achieve good effect and can replace the new wood completely

Features:

1. Fixed length, lengthwise connection, manual truncation of ideal length.Reduce the intensity of labor.

2. The operation mode of manual feeding - butt forming - manual discharging is simple and efficient

3. High quality motor makes the power supply sufficient and the service time longer

Advantage:

1. It can improve the utilization rate of wood, reduce the waste of resources, and achieve the purpose of long-term use of short materials and optimal use of inferior materials.

2. The wide platform can make the processing more smooth.

3. Simple operation button. After simple learning, workers can easily master the use method of the equipment and reduce their labor intensity.

4. High cost performance, it is the first choice for small and medium-sized enterprises to receive wood equipment.

Parameter:

Max.working length2500mm
Max.thrust for oil pressure4000kg
Worktable size2500x350mm
Max.working thickness70mm
Oil pump power2.2kw
Cut off saw power1.5kw
Main spindle speed2840r/min
Max.blade diameter305mm
Working air pressure0.8MPa
Packing size3700x1100x1600mm
Overall size3600×1050×1500mm
Net  weight500kg

Packing&Service

1.Delivery:
We can guarantee delivery on time.
We also can sign on-time delivery contracts. If we can’t deliver on time, we will give the product a corresponding discount.
2.Package:
We will take care of your machinery packages well like picture show.
Our workers will make sure your machine clean before package.
We will add stretchy film for the whole machine and spare parts for delicate protection.
We will make export standard strong Wooden box case package as your request.
3.Guarantee:
The machine is guaranteed for 12 months .Within 12 months under normal using and maintenance, if the machine has something problem ,you will get spare part for free . More than 12 months,you will get the cost price for accessories. You will also get technical support and service all the time.
4.Technical support:
Technical support by Phone, Email, Wechat, WhatsApp and Skype, 24 hours online.
We provide English version manual and Operational video.
Engineer available to service machinery overseas.
5. After sales services:
Our machine is installed and tested well before delivery. You can operate the machine immediately after receiving machine.
If you don't know how to use the machine, we will offer you free training until you can use machine freely. And If there is still have any question, please contact us by Email, Skype, Wechat, WhatsApp, Phone and Trade Manager online service at any time.
